OpenHantek6022

OpenHantek6022 is a free software for Hantek DSO6022 USB digital signal oscilloscopes that is actively developed on
github.com/OpenHantek/OpenHantek6022 — but only for Hantek 6022BE/BL and compatible scopes (Voltcraft, Darkwire, Protek, Acetech, etc.).

This project gives no support for its currently unmaintained predecessor openhantek.

Content

• About OpenHantek6022
• Features
• AC Coupling
• Continuous Integration
• Building OpenHantek6022 from source
• Install Prebuilt Binary Packages
• Run OpenHantek6022
  • Offset Calibration
  • OpenGL Support
  • USB Access
• Important!
• Specifications, Features, Limitations and Developer Documentation
• Contribute
• Donate

• Other DSO Open Source Software
• Other Related Software
• History

About OpenHantek6022

• Supported devices:

  • Hantek 6022BE and 6022BL as well as compatible scopes (e.g. Voltcraft DSO-2020).
  • SainSmart DDS120 (thx msiegert) — this device has a different analog front end
    and uses the slightly improved sigrok firmware, which has some limitations
    compared to the Hantek scopes (see #69).

• Demo mode is provided by the -d or --demoMode command line option.

• Fully supported operating system: Linux; developed under debian stable (currently bookworm) for amd64 architecture.

• Raspberry Pi packages (raspbian stable) are available on the Releases page, check this setup requirement.

• Compiles under FreeBSD (packaging / installation: work in progress, thx tspspi).

• Other operating systems builds: Windows (mostly untested) & macOS (completely untested).
  No support for non-Linux related issues unless a volunteer steps in!

• Uses free open source firmware, no longer dependent on nonfree Hantek firmware.

• Extensive User Manual with technical specs and schematics.

Features

• Voltage and Spectrum view for all device supported channels.
• CH1 and CH2 name becomes red when input is clipped (bottom left).
• Settable probe attenuation factor 1..1000 to accommodate a variety of different probes.
• Measure and display Vpp, DC (average), AC, RMS and dB (of RMS) values as well as frequency of active channels.
  Display as dBV (0 dBV = 1 V rms), dBu (0 dBu = 1 mW @ 600 Ω) or dBm (0 dBu = 1 mW @ 50 Ω) can be selected in Oscilloscope/Settings/Analysis.
• Display the power dissipation for a load resistance of 1..1000 Ω (optional, can be set in Oscilloscope/Settings/Analysis).
• Display the THD of the signal (optional, can be enabled in Oscilloscope/Settings/Analysis).
• Show the note values and deviation in cent (twelve equal, A = 440 Hz) for audio frequencies (optional, can be enabled in Oscilloscope/Settings/Analysis). Useful to tune e.g. your electrical guitar.
• Math channel modes: CH1+CH2, CH1-CH2, CH2-CH1, CH1*CH2 and square, abs, sign, AC and DC part of CH1 or CH2.
• Time base 10 ns/div .. 10 s/div.
• Sample rates 100, 200, 500 S/s, 1, 2, 5, 10, 20, 50, 100, 200, 500 kS/s, 1, 2, 5, 10, 12, 15, 24, 30 MS/s (24 & 30 MS/s in CH1-only mode, 48 MS/s not supported due to unstable USB data streaming).
• Hardware input gain automatically selected based on vertical sensitivity: 1x (up to ±5 V for 1, 2 or 5 V/div), 2x (up to ±2.5 V for 500 mV/div), 5x (up to ±1 V for 200 mV/div) and 10x (up to ±500 mV for 20 or 50 mV/div).
• Downsampling (up to 200x) increases resolution and SNR.
• Calibration output square wave signal frequency can be selected between 32 Hz .. 100 kHz in small steps (poor person’s signal generator).
  A little HW modification provides a jitter free HW-driven calibration output signal instead of the interrupt driven SW-output.
• Trigger modes: Normal, Auto and Single with green/red status display (top left).
• Untriggered Roll mode can be selected for slow time bases of 200 ms/div .. 10 s/div.
• Trigger filter HF (trigger also on glitches), Normal and LF (for noisy signals).
• Display interpolation modes Off, Linear, Step and Sinc.
• Calibration values loaded from eeprom or a model configuration file.
• Online offset calibration creates a configuration file for persistent data storage.
• Calibration program to create these values automatically.
• Digital phosphor effect to notice even short spikes; simple eye-diagram display with alternating trigger slope.
• Histogram function for voltage channels on right screen margin.
• A zoom view with a freely selectable range.
• Cursor measurement function for voltage, time, amplitude and frequency.
• Export of the graphs to JPG, PNG or PDF file or to the printer; data export as CSV or JSON.
• Freely configurable colors.
• Automatic adaption of iconset for light and dark themes.
• The dock views on the main window can be customized by dragging them around and stacking them.
  This allows a minimum window size of 800*300 for old laptops or workstation computers.
• All settings can be saved to a configuration file and loaded again.
• French, German, Russian and Spanish localisation complete; Chinese, Polish and Swedish is updated regularily; Italian and Portuguese translation ongoing — volunteers welcome!

AC Coupling

A little HW modification adds AC coupling. OpenHantek6022 supports this feature since v2.17-rc5 / FW0204.

Continuous Integration

Every commit triggers a workflow on
GitHub Actions
that builds and packages OpenHantek6022 for:

• Linux (*.deb, *.rpm, *.tar.gz)
• Windows (*_mingw_x64.zip, *_msvc_x64.zip)
• macOS — (*.dmg, *.tar.gz)

This status badge here (and on top) show the build status.

Building OpenHantek6022 from source

The preferred way to run OpenHantek6022 is to build it from source on your system, especially under Linux.

The easiest way to get an up-to-date working code base is to clone the code from here via

git clone https://github.com/OpenHantek/OpenHantek6022.git

and then build it locally, for this you will need the following software:

• CMake 3.5+
• Qt 5.4+
• FFTW 3+ (prebuild files will be downloaded on windows)
• libusb-1.0, version >= 1.0.16 (prebuild files will be used on windows)
• A compiler that supports C++11 — tested with gcc, clang and msvc

We have build instructions available for Linux, Raspberry Pi, FreeBSD, Apple macOS and Microsoft Windows.

To make building for Linux even easier, I provide two shell scripts:

• LinuxSetup_AsRoot, which installs all build requirements. You only need to call this script once (as root) if you have cloned the project.
• LinuxBuild configures the build, builds the binary and finally creates the packages (deb, rpm and tgz) that can be installed as described in the next paragraph.
  If you make small changes to the local source code, it is sufficient to call make -j4 or fakeroot make -j4 package in the build directory.

Install Prebuilt Binary Packages

Run OpenHantek6022

On a Linux system start the program via the menu entry OpenHantek (Digital Storage Oscilloscope) or from a terminal window as OpenHantek.

You can explore the look and feel of OpenHantek6022 without the need for real scope hardware by running it from the command line as: OpenHantek --demoMode.

Note: To use the 6022BL in scope mode, make sure the «H/P» button is pressed before plugging in.

Using Hantek 6022BL LA Function

The Hantek6022BL can either be used as oscilloscope or as logic analyzer,
but not both at the same time — it is not a mixed-signal-oscilloscope (MSO).
If you want to use the LA part, then sigrok is the way to go, it works (besides Linux) also for MacOS and Windows.
There is no point in supporting the LA input from OpenHantek.

Offset Calibration

The oscilloscope has quite a large zero point error. To calibrate the offset quickly, simply proceed as follows:

1. Short-circuit both inputs, e.g. with a 50Ω terminating plug or by short-circuiting the probe inputs.
2. Activate the menu setting Oscilloscope/Calibrate Offset.
3. Set a slow timebase of 10..100 ms/div, resulting sample rate is 100..10 kS/s.
4. Slowly select all voltage settings for CH1 and CH2 one after the other.
5. Finally deactivate the menu setting Oscilloscope/Calibrate offset.

The offset correction is now active and is also permanently saved in EEPROM or as an *.ini file when switched off.

OpenGL Support

OpenHantek6022 uses the OpenGL graphics library to display the data. It requires a graphics card that supports
3D rendering and runs on legacy HW/SW that supports at least OpenGL 2.1+ or OpenGL ES 1.2+.
OpenGL is selected by default, but if this does not work (i.e. the black scope window shows an error message
or closes immediately after startup), you can choose the less resource-hungry OpenGL ES variant as a fallback
by starting OpenHantek from the command line as follows: OpenHantek -e or OpenHantek --useGLES.

Especially on Windows, this option may be necessary to use the program.

It has been reported that the MINGW binary build on some Windows systems had problems with the graphical display
and led to a black screen without traces. In these cases, the switch to the MSVC binary build can help.

Similar issues with Linux on ChromeOS (Crostini) can be solved by setting the environment variable LIBGL_ALWAYS_SOFTWARE=1 when using OpenHantek.
This could also be a solution for the above MINGW issue, see e.g. #360
and #388 — not yet confirmed.

The Raspberry Pi build uses OpenGL ES automatically, check also the graphics driver setup.

USB Access

USB access for the device is required (unless using demo mode):

• Linux/Unix
  You need to copy the file utils/udev_rules/60-openhantek.rules to /etc/udev/rules.d/ or /usr/lib/udev/rules.d/ and replug your device.
  Note: If OpenHantek is installed from a *.deb or *.rpm package this file is installed automatically into /usr/lib/udev/rules.d/.

• Windows
  Caution: The original Hantek driver for Windows doesn’t work!
  You have to assign the correct WinUSB driver:

  • The signed .inf file OpenHantek.inf for all devices — provided by VictorEEV
    and updated by gitguest0 —
    is available in the openhantek_xxx_win_x64.zip binary distribution in directory driver.

  • Right-click on OpenHantek.inf and select «install» from the pull-down menu.

  • The Device Manager will show (under «Universal Serial Bus devices») the name and state according to the firmware loaded (e.g. Hantek 6022BE - Loader, Hantek 6022BE - OpenHantek).
    The PulseView/sigrok-cli firmware is also recognized (e.g. Hantek 6022BE - Sigrok).

  It is recommended to use the .inf file, but it is also possible to alternatively use the Zadig tool
  and follow the good step-by-step tutorial provided by DaPa.

Important!

The scope doesn’t store the firmware permanently in flash or eeprom, it must be uploaded after each power-up and is kept in ram ’til power-down.
If the scope was used with a different software (old openhantek, sigrok or the windows software) the scope must be unplugged and replugged one-time before using it with OpenHantek6022 to enable the automatic loading of the correct firmware.
The top line of the program must display the correct firmware version (FW0210).

Specifications, Features, Limitations and Developer Documentation

I use this project mainly to explore how DSP software can improve and extend the limitations
of this kind of low level hardware. It would have been easy to spend a few bucks more to buy a powerful scope — but it would be much less fun
Please refer also to the developer info.

Contribute

We welcome any reported GitHub issue if you have a problem with this software. Send us a pull request for enhancements and fixes. Some random notes:

• Read how to properly contribute to open source projects on GitHub.
• Create a separate branch other than main for your changes. It is not possible to directly commit to main on this repository.
• Write good commit messages.
• Use the same coding style and spacing -> install clang-format and use make target: make format or execute directly: clang-format -style=file -i *.cpp *.h.
• It is mandatory that your commits are Signed-off-by:, e.g. use git’s command line option -s to append it automatically to your commit message:
  git commit -s -m 'This is my good commit message'
• Open a pull request with a clear title and description.
• Read Add a new device if you want to know how to add a device.
• We recommend QtCreator as IDE on all platforms. It comes with CMake support, a decent compiler, and Qt out of the box.

Other DSO Open Source Software

• Firmware used by OpenHantek and python bindings for 6022BE/BL
• sigrok
• Software for the Hantek 6022BE/BL (win only)

Other Related Software

• HScope for Android A one-channel basic version is available free of charge (with in-app purchases).

History

The program was initially developed by David Gräff and others
on github.com/OpenHantek/openhantek,
but David stopped maintaining the programm in December 2018.
